Elite Series LED Fog Lamps are OEM-style replacements that deliver up to five times more output than factory halogen fog lights. Built with premium optics and durable construction, they drop right into the factory fog lamp location for a clean upgrade. This guide covers the universal installation process — while vehicle access points may vary, the core steps are the same across all applications.
Table of Contents
- Tools Required
- Installation Instructions
- Aiming Instructions
- Questions About the Install?
- Shop Elite Series Fog Lamps at Ess K Customs
Tools Required
- Basic hand tools (varies by vehicle)
- Trim or panel removal tool (if required)
- Included wire adapters and T-taps
Time Required: Approximately 45–90 minutes.
Installation Instructions
Step 1 — Access the factory fog lights by reaching down behind the bumper near the headlight, or by pulling back the wheel well liner, depending on your vehicle.
Step 2 — Disconnect the fog light connector from the vehicle wiring harness. Remove the factory fog light housing from the bumper. The factory mounting hardware will be reused.
Step 3 — Install the new Elite Series LED Fog Lamp using the factory mounting points and hardware. If your vehicle uses side-specific lamps, the correct side will be labeled on the back of the lamp. Make sure the mounting tabs and holes align with the factory bracket before tightening.
Step 4 — Use the included wire adapters to connect the fog lamp to the vehicle wiring harness. Test the light for proper operation. If the lamp doesn't turn on, flip the connector 180 degrees and test again.
Step 5 (Backlight Feature) — If your Elite Series fog lamps include a backlight feature, connect the backlight power wire to a fused 12V source such as the parking light or sidemarker circuit. Use the included T-taps to make the connection.
NOTE: The power source must be fused. Do not connect the backlight wire directly to the vehicle battery. Check local laws regarding on-road use of backlighting.
Step 6 — Repeat Steps 1–5 for the fog lamp on the other side of the vehicle.
Aiming Instructions
Step 7 — Park the vehicle on a level surface 25 feet from a wall or garage door.
Step 8 — Measure the distance from the ground to the center of the fog lamp. This is your mounting height.
Step 9 — Mark the mounting height on the wall with tape. Place a second strip of tape four inches below — this is your fog light cutoff line.
Step 10 — Using the integrated adjustment screw on each fog lamp, aim the beam so the top of the beam pattern aligns with the cutoff line.
Questions About the Install?
If you run into any issues during the installation, contact Ess K Customs — as an authorized Diode Dynamics dealer, we're here to help.
Shop Elite Series Fog Lamps at Ess K Customs
Ready to upgrade your fog lights? As an authorized Diode Dynamics dealer, Ess K Customs carries the full lineup of Elite Series LED Fog Lamps with full manufacturer warranty. Find the right fit for your vehicle below.
Shop Elite Series Type A Fog Lamps →
Browse All Elite Series Fog Lamps at Ess K Customs →
This install guide applies broadly to Diode Dynamics Elite Series LED Fog Lamps.
