Multicolor DRL LED Boards for the 2016–2018 Chevrolet Camaro SS transform the factory lower daytime running lights into a fully customizable RGBW accent with an integrated amber turn signal. These boards are a direct replacement for the factory lower DRL LED panels inside the headlight. Because this install requires opening the headlights, professional installation is strongly recommended.
Table of Contents
- Tools Required
- Installation Instructions
- Questions About the Install?
- Shop Camaro Lighting at Ess K Customs
Tools Required
- Torx T10 screwdriver
- Torx T20 screwdriver
- Basic hand tools for headlight removal
- Heat gun or oven (for opening headlights)
Time Required: Approximately 3–5 hours.
Important: Headlights must be opened before proceeding. Before baking the headlight, remove the T20 Torx screws holding the ballast and LED driver to the housing, and disconnect the OEM harness from the ballast. Professional installation is strongly recommended.
Installation Instructions
Step 1 — Remove the headlights from the vehicle. Open the headlight housings by heating and carefully separating the lens from the housing.
Step 2 — After the lens has been removed, remove the three T20 Torx screws holding the lower DRL reflector in place. Then remove the three T20 Torx screws securing the factory lower DRL LED board to the reflector. Remove the factory board — it won't be reused.
Step 3 — Install the new lower DRL LED board in place of the factory board using the original screws. Make sure the board is properly aligned and securely fastened.
Step 4 — Using the original screws, reinstall the reflector back into the headlight housing. Repeat Steps 2–4 for the other headlight.
Step 5 — Connect the lower DRL LED board to the RGBW driver. Then connect the driver to the RGBW controller using the included JST-to-M8 adapter and extension wiring as needed. Do not connect the LED board directly to the controller without the driver — the driver is required to regulate power.
Step 6 — Tap the wiring harness to the appropriate factory signals to determine DRL operation:
- Black wire: Ground
- Yellow wire: Turn signal input
- Blue wire: Parking/DRL signal
These connections control when the DRL boards illuminate and activate the amber turn signal function.
Step 7 — Mount the driver and controller outside of the headlight housing for serviceability, in a location away from the engine block to prevent excessive heat buildup. Test the system thoroughly to confirm proper RGBW and turn signal operation.
Step 8 — Once testing is complete, reseal the headlight housings and reinstall them on the vehicle. The install is complete.
Questions About the Install?
If you run into any issues during the installation, contact Ess K Customs — as an authorized Diode Dynamics dealer, we're here to help.
Shop Camaro Lighting at Ess K Customs
Looking to upgrade your Camaro's lighting? As an authorized Diode Dynamics dealer, Ess K Customs carries genuine products with full manufacturer warranty.
Shop LED Sidemarkers for 2016-2024 Chevrolet Camaro →
This install guide applies to Diode Dynamics SKU: DD2242
