If you're installing the Diode Dynamics Add-On Fog Light Kit on your 2024+ Ford Mustang GT, you may want to reinstall the factory backing plate behind the new fog lamp. This isn't a required step, but if you want the OEM finish behind the light, the panel needs to be trimmed for clearance. This guide walks you through the cutting process using the printable template.
Table of Contents
- Download the Template
- Tools Needed
- Cutting Instructions
- Questions About the Installation?
- Shop Mustang Lighting at Ess K Customs
Download the Template
Download the blockoff panel cut template directly from Diode Dynamics:
Download the 2024+ Mustang GT Fog Light Blockoff Panel Cut Template (PDF) →
Important: Print the template at 100% scale. Do not use "fit to page" or any scaling settings. Verify accuracy by measuring the 5-inch reference line printed on the template before cutting.
Tools Needed
- Scissors
- Cutting device (rotary tool or utility knife)
- 7mm socket
- OEM screws (from original panel)
- Protective gloves and eye protection
Cutting Instructions
Step 1 — Print the template PDF on standard 8.5x11" paper at 100% scale. Verify the scale is correct by measuring the 5-inch reference bar printed at the top of the page.
Step 2 — Use scissors to cut out the outline of the template along the marked borders.
Step 3 — Place the paper template over your OEM blockoff panel and align the shape carefully to match the mounting points and contour.
Step 4 — Use your preferred cutting tool to trim the plastic panel along the curved edge as marked on the template.
Step 5 — Install the modified blockoff panel onto the Diode Dynamics fog lamp bracket using a 7mm socket and the original OEM screws.
Warning: Always use proper protective equipment and follow tool manufacturer instructions when cutting.
