Stage Series LED Light Bars deliver high-performance off-road and auxiliary lighting with advanced TIR optics, durable aluminum construction, and a slim mounting profile. This guide covers the general mounting and wiring process for Stage Series LED Light Bars. While it references a 6-inch light bar, the same principles apply across the entire Stage Series lineup.
Table of Contents
- Tools Required
- Installation Instructions
- Questions About the Install?
- Shop Stage Series Light Bars at Ess K Customs
Tools Required
- Basic hand tools (wrenches, sockets, or Allen keys depending on mounting method)
- 16 AWG or larger wiring (if not using a Diode Dynamics wiring harness)
- Optional: Diode Dynamics wiring harness and switch
Time Required: Approximately 30–60 minutes per light bar.
Installation Instructions
Step 1 — Choose a suitable mounting location for the Stage Series LED Light Bar. These lights are compatible with many standard mounting brackets and can also be mounted using the included hardware. Check the product dimensions to ensure proper clearance and fitment.
Step 2 — Using the included mounting hardware, attach the brackets to the light bar. Leave the hardware slightly loose so the light can be adjusted after final installation.
Step 3 — Mount the light bar to the vehicle using the selected mounting points. Once properly positioned, tighten all mounting hardware securely.
Step 4 — Connect the red wire to a positive power source and the black wire to a negative or common ground. Stage Series LED Light Bars draw high current, so make sure you're using adequately sized wiring. If you're not using a Diode Dynamics wiring harness, 16 AWG wire or larger is recommended. If using a Diode Dynamics wiring harness on a 24V system, the relay must be replaced with a 24V-rated relay.
Step 5 — Power on the light bar to verify proper operation. Adjust the beam angle as needed, then fully tighten all mounting hardware once you've dialed in the aim.
Questions About the Install?
If you run into any issues during the installation, contact Ess K Customs — as an authorized Diode Dynamics dealer, we're here to help.
Shop Stage Series Light Bars at Ess K Customs
Ready to add Stage Series LED Light Bars to your build? As an authorized Diode Dynamics dealer, Ess K Customs carries the full lineup — different sizes, beam patterns, and output colors — with full manufacturer warranty.
Browse All Stage Series LED Light Bars at Ess K Customs →
This install guide applies broadly to Diode Dynamics SKUs: DD5014S, DD5014P, DD5022S, DD5022P, DD5036S, DD5044S, DD5044P
