LED Sidemarkers for the 2015–2023 Ford Mustang (EU/AU specification) replace the factory sidemarkers with a brighter, more modern LED solution. These sidemarkers install cleanly using the included wiring harness with minimal modification. Here's the full install walkthrough for EU/AU-spec Mustangs.
Table of Contents
- Tools Required
- Installation Instructions
- Questions About the Install?
- Shop Mustang LED Sidemarkers at Ess K Customs
Tools Required
- Included T-tap wiring connectors
- Trim or panel removal tool (optional)
Time Required: Approximately 30–45 minutes.
Installation Instructions
Step 1 — Using the included T-taps, connect the pink connectors on the supplied wiring harness to a positive and negative signal wire that activates when the tail lights are on. Tapping into the license plate light wiring is recommended. Once connected, route one connector to each sidemarker location on both sides of the vehicle.
Step 2 — Reach behind the factory sidemarker and depress the tab on the side closest to the wheel well. Once the tab is released, slide the sidemarker toward the wheel well and pull it out of the body. The factory sidemarker will not be reused.
Step 3 — Plug the new LED sidemarker into the previously installed wiring harness connector.
Step 4 — Slide and clip the new LED sidemarker into place. Make sure all wiring is tucked safely away from any heat sources, including the exhaust.
Questions About the Install?
If you run into any issues during the installation, contact Ess K Customs — as an authorized Diode Dynamics dealer, we're here to help.
Shop Mustang LED Sidemarkers at Ess K Customs
Ready to upgrade your Mustang's sidemarkers? As an authorized Diode Dynamics dealer, Ess K Customs carries genuine products with full manufacturer warranty.
Shop LED Sidemarkers for 2015-2023 Ford Mustang →
This install guide applies to Diode Dynamics SKUs: DD5071, DD5072, DD5073
